The Iridium VENUS IR antenna is based on a ceramic patch and patented filtering mechanism. The VENUS is a very popular design produced by Webb Industries for their GSM/GPS, GSM/GPS/WLAN range of antennas. Contact us for more details on this and other products for Iridium.Application:Tracking and Monitoring
* E' BENE CHIEDERE UN PREVENTIVO quando dovete abbinare prodotti particolari come un antenna ed il cavo, noi vi possiamo suggerire il cavo corretto per connettere il vostro telefono o la dock all'antenna scelta o aiutarvi a scegliere il prodotto migliore per le vostre esigenze.
| ELECTRICAL DATA | Iridium | GPS |
| Frequency Range | 1616-1626 MHz | 1575 MHz |
| Element Gain (exl.cable) | 4 dB | 5 dBiC |
| Amplifier Gain | - | 24 dB +/- 1 dB |
| Max. Axial Ratio | - | < 3dB |
| VSWR | 1.5:1 | < 2:1 |
| Rated Power | 10 W | 1W |
| Polarisation | RHCP | RHCP |
| Voltage | - | 3-5 V |
| Isolation/Decoupling | 12 dB | 12 dB |
| Noise Figure | - | 2 dB max. |
| Current Sink | < 20 mA | |
| Amplifier DC Power | - | 3 to 5 VDC on coax cable (+ve centre) |
| Impendance | 50 Ohms | 50 Ohms |
EUR 91,43 + IVA
(USD 95,00)
